45762101TH Rev.1
3-18
Unit name display Drive restriction condition Remarks
MAIN MOTOR - -
EXIT MOTOR FWD FaceUp Cover close -
EXIT MOTOR REV FaceUp Cover open -
REGIST CLUTCH MAIN MOTOR driving -
T1 HOP CLUTCH MAIN MOTOR driving -
MPT HOP CLUTCH MAIN MOTOR driving -
T2 HOP CLUTCH TRAY2 MOTOR driving OPTION
T2 REG CLUTCH TRAY2 MOTOR driving OPTION
LV FAN TEST - -
FUSER FAN TEST - -
ID FAN TEST - -
Note! The rollers that rotate continuously (each of heat rollers, image drums, and
conveying rollers) run in synchronization with the main motor.
Table 3-4
