45762101TH Re
v
.1
4-30
Oki Data CONFIDENTIAL
4.REPLA
CEMENT OF P
AR
TS
(4)
Disconnect cab
les (4 point)
⑤
from the CU/PUBoard
⑥
.
(5)
Remov
e the PWR unit-AC
DC Switch.
(Refer to 4.2.4).
(6)
Unlatch
the cla
ws (2poi
nts),
and remo
v
e the Moto
r-F
AN (60 x 25)
⑦
from
the Duct
F
an P
ower
⑧
.
⑥
⑤
⑦
Air
Claw
⑧
⑨
⑧
⑪
⑩
(7)
Remov
e three screws (Silv
er)
⑨
to detach Duct F
an P
owe
r
⑧
.
(8)
Remov
e three scre
ws(Silv
er)
⑩
to detach DC Motor
⑪
.
Note!
(to assemble)
1.
Note to asse
mb
le f
or th
e dire
ction of th
e Motor
-F
AN's ai
r flow
.
149
