4-92 Service Manual

Cover scanner left

1. Remove the flatbed assembly. See “Flatbed removal” on page 4-72.

2. Release the tabs (A) securing the left flatbed cover to the flatbed unit using a small flatblade screwdriver.

Y112730-2
