Olivetti d-Color MF920 Service Manual

2-44 Service Manual
Operator panel displays all diamonds, no beeps
Operator panel displays all diamonds, five beeps
Step Questions / actions Yes No
1 Turn off the printer, and remove the rear
shield. See “Rear shield removal” on
page 4-7. Disconnect the cable at JOPP1 on
the controller board. Verify the following
values:
Are all these values approximately correct?
Go to step 2. Replace the controller
board. See “Controller
board removal” on
page 4-18.
2
Check for continuity in the operator panel
cable connector.
Do all the conductors indicate continuity?
Replace the operator panel.
See “Operator panel
removal” on page 4-98.
Replace the operator panel
cable. See “Op panel
cable” on page 4-101
Step Questions / actions Yes No
1 Turn off the printer, and remove the rear
shield. See “Rear shield removal” on
page 4-7. Disconnect the cable at JOPP1 on
the controller board. Verify the following
values:
Are all these values approximately correct?
Go to step 2. Replace the controller
board. See “Controller
board removal” on
page 4-18.
2
Check for continuity in the operator panel
cable connector.
Do all the conductors indicate continuity?
Replace the operator panel.
See “Operator panel
removal” on page 4-98.
Replace the operator panel
cable. See “Op panel
cable” on page 4-101
JOPP1
Pin Voltage
10 V dc
2 +5 V dc
30 V dc
4 Ground
5 +5 V dc
6 +3.3 V dc
7 Ground
JOPP1
Pin Voltage
10 V dc
2 +5 V dc
30 V dc
4 Ground
5 +5 V dc
6 +3.3 V dc
7 Ground
Y112730-2
