3-10 Service Manual
Factory Scanner
Note: This setting is not used by field service.
Factory Manual
Note: This setting is not used by field service.
Miscellaneous Tests
Motor Detect
This test initiates an automatic motor detection process that should be performed whenever the controller board
is replaced.
To run Motor Detect:
1. Select MISC TESTS in the Diag Menu, and press Select ().
Remove Cartridge. press Select appears.
2. Select Motor Detect.
Note: Do not press Select yet.
3. Remove all toner cartridges and the imaging unit.
4. Close the front cover.
If you press Select before closing the front cover, a message appears: Close Cover. press Select.
5. press Select ().
Motor Detection In Progress… appears.
The motor detection process takes about 10 seconds, and stops automatically.
Detect Complete. Rebooting… appears, and the printer performs a POR (Power On Reset).
Y112730-2
