Olivetti d-Color MF920 Service Manual

5-16 Service Manual
Connectors
HVPS board
Connector Pin no. Signal
Connection from controller board 1 M-Drpwm
2 K-Drpwm
3C-Drpwm
4CMY-Chrgpwm
5Y-Drpwm
6 K-Chrgpwm
7 CMY-Srvo_Out
8I-Txpwm
9CMY-Txpwm
10 I-Srvo_Out
11 K-Srvo_Out
12 K-Txpwm
13 +24V
14 +24VRtn
15 VREF Buffered
16 +24VRtn
Contacts to machine 1 I-Transfer
2 CMY-Transfer
3 K-Transfer
4 K-Charge
5 CMY-Charge
6 K-DR Blade
7 M-DR Blade
8 C-DR Blade
9 Y-DR Blade
10 Ground
Y112730-2
