Diagnostic information 2-3
Symptom tables
Printer symptom table
Symptom Action
Dead printer Go to “Dead printer service check” on page 2-35.
Operator panel—one or more buttons do
not work.
Go to “One or more operator panel buttons fail” on
page 2-42.
Operator panel—display is blank. Printer
sounds five beeps.
Go to “Operator panel display blank, five beeps” on
page 2-42.
Operator panel—display is blank. Go to “Operator panel display blank, five beeps” on
page 2-42.
Operator panel continuously displays all
diamonds and does not complete POST.
Go to “Operator panel display blank, five beeps” on
page 2-42.
Pages print blank after replacing the
controller board.
When replacing the controller board, verify the cable from the
high-voltage power supply is seated properly. The cable may
have come loose from the HVPS.
Warning: A blank page that should have toner on it could be an
indication that toner is applied to the ITU belt but not transferred.
Therefore the toner goes into the ITU cleaner which cannot
process massive amounts of toner. It is important to prevent
extensive blank pages from being processed if they should have
toner on them.
Tray linking does not work. • Check that the same size and type of paper are in each tray.
• Check the location of the paper guides.
• The multipurpose feeder does not automatically sense the
paper size. You must set the size from the Paper Size/Type
menu.
• Print a menu settings page, compare the settings for each
tray, and adjust on the operator panel, if necessary.
Unexpected page breaks occur • Increase the Print Timeout value on the operator panel
(Settings–>General Settings–>Timeouts–>Print Timeout).
Multipurpose feeder has constant misfeeds
or jams.
• Remove and flex the paper in the tray. Reload the paper,
and try printing.
• Turn the paper over inside the tray.
• Make sure the feeder is properly installed.
• Make sure the paper is loaded correctly in the tray.
• Make sure the paper is not damaged.
• Make sure the paper meets specifications. See “Media
input type specifications” on page 1-11.
• Make sure the paper guides are positioned correctly for the
paper size loaded in the tray.
Page that jammed does not reprint after
you clear the jam.
Jam Recovery may be set to Off. Change the setting to Auto or
On on the operator panel (Settings–>General settings–>Print
Recovery–>Jam Recovery.)
Printing speed reduced for more than 10
pages. May happen after a service call.
Check the narrow media sensor cable is correctly connected at
the sensor, and the cable is correctly connected to JBIN1 on the
controller board.
Pages print blank after replacing the
controller board.
When replacing the controller board, verify the cable from the
high-voltage power supply is seated properly. The cable may
have come loose from the HVPS.
Warning: A blank page that should have toner on it could be an
indication that toner is applied to the ITU belt but not transferred.
Therefore the toner goes into the ITU cleaner which cannot
process massive amounts of toner. It is important to prevent
extensive blank pages from being processed if they should have
toner on them.
Y112730-2
