Locations 5-5
Connectors
Controller board
Connector Pin no. Signal
JUSB1 Port G1 Ground
1 USB_5V_Sense
2 USB D-
3 USB D+
4 Ground
G2 Ground
JUSBW1 1 Ground
2 USB_HST_VP
3 USB_HST_VM
4 Ground
5 +3.3 V
6 +3.3V
JFAN1 1 FAN_FG, 3.3V
2 Ground
3V_FAN_P3
JMIRR1 1 MM_REFR
2 MM_LOCK, +3.3 V dc
3 MM_START
4GND
5 +24V_VC
JCTM1 1 +5V
2 CART_METER_C_IN
3CART_METER_M_IN
4 CART_METER_Y_IN
5 CART_METER_K_IN
6GND
Y112730-2
