1-16 Service Manual
Digital imaging specifications
General specifications
ADF Scan speed
Simplex ADF - Up to 5 ppm
Duplex ADF - Up to 5 ppm (page sides)
ADF Document handling
ADF input capacity - 50 sheets.
ADF output capacity - 50 sheets.
ADF document width - 4.9” (125mm) to 8.5”(216mm)
ADF document length - 5” (127mm) to 14.0”(356mm)
Resolution and color depth
•
Resolution - 1200 dpi optical
• CDD 1200 dpi, and 600 dpi. Selectable through electronics
• Color depth - 48 bit RGB output. 16 bit / channel
Flatbed document specifications
•
Document size- Up to A4 and letter
4.5” x 5.5” to 8.5”x11” (SEF)
Flatbed speed
3 seconds to scan, 3 seconds to return.
Scanner operating environments
•
Temperature - 10C to 35C
• Humidity - 15% RH to 85% RH
Storage environments
•
Temperature - -20C to 43C
• Humidity - 5%RH to 95% RH
Tilt
This device should operate within the stated parameters when it is level within 10mm from front to back and
10mm side to side.
Y112730-2
