1-18 Service Manual
Fax specifications
Phone network connectivity
Fax resolutions
Miscellaneous FAX specifications
Phone networks types supported PSTN or analog PABX (RJ-11)
ITU COMPATIBILITY
Standard Resolution
Fine
Superfine
Ultrafine
Coding
Group 3/ECM
8 x 3.85 pels/mm (200X100dpi) (204x98)
8 x 7.7 pels/mm (200X200dpi) (204x196)
11.8 x 11.8 pels/mm(300x300 dpi) (204x391)
15.7 x 15.7 pels/mm (400x400 dpi) (408x391)
ITU T.4 and T.6(MH, MR, MMR, JPEG)
Modem speed V.34 2,400-33,600 BPS,
V.17 7,200-14,400 BPS,
V.27 2,400-4,800 BPS,
V.29 7,200-9,600 BPS
Compression
MH, MR, MMR, JPEG
Error correction ITU T.30
Line interface selection
Modular Plug
Out Band Signal Level
Dual RJ-11C
Guaranteed North American and Europe PTT standard
Input Level Range
Ring Detection
-16dBm ~ -59dBm
Complies with all regulatory requirements
Receive 200x100 dpi, 200x200 dpi, 300x300 dpi,
400x400 dpi, 204x98 dpi, 204x196 dpi,
204x391 dpi, 408x391 dpi
Send 200x100dpi, 200x200 dpi, 300x300 dpi
Fax memory 4 MB Flash (More than 320 pages based on ITU chart #1)
User selectable parameters are stored in NVRAM.
Speed dial Yes. 99 entries
Transmission Approximately 3 seconds per page
Color fax Yes
Fax from PC Yes. Supported using PostScript driver for both local and
network attach modes.
Caller ID Yes
Junk FAX blocking Yes - based on caller ID and remote station ID
Tone/Pulse Tone: Default, Pulse: Yes
Fax forward Yes
Broadcasting Yes. 12 destinations
External phone interface Yes
Manual mode Yes
Fax shortcuts Yes.
Fax content Text, text/photo, photo
Fax preservation Yes
Halftoning Yes
Y112730-2
