Omron CQM1H - 08-2005 User Manual

65
Output Unit Specifications Section 2-3
Item CQM1-OD213
Name 32-point Transistor Output Unit
Max. Switching Capacity 16 mA at 4.5 V DC to 100 mA at 26.4 V (see diagram below)
Leakage Current 0.1 mA max.
Residual Voltage 0.8 V max.
ON Delay 0.1 ms max.
OFF Delay 0.4 ms max.
No. of Outputs 32 points (32 points/common, 1 circuit)
Internal Current Consump-
tion
240 mA max. at 5 V DC
Fuse 3.5 A (one per common), one used
Fuse is not user replaceable.
Service Power Supply 110 mA min. at 5 to 24 V DC ±10% (3.4 mA × number of ON points)
Weight 180 grams max.

Omron CQM1H - 08-2005 Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Omron
Program Capacity	3.2K steps
Model	CQM1H
I/O Points	512 points max
