Omron CQM1H - 08-2005 User Manual

66
Output Unit Specifications Section 2-3
Circuit Configuration
Item CQM1-OD213
4.5 20.4 26.4
100
16
Max. Switch Capacity (per Point)
+V (V)
50
10
Units manufactured on or before December 28th, 1999
(manufacturing numbers 28Z9 or earlier)
Fuse
3.5 A
Output
LED
OUT00
OUT07
COM
A
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to 26.4 V DC
4.5 to 26.4 V DC
OUT00
OUT07
COM
B
OUT08
OUT15
COM
4.5 to 26.4 V DC
4.5 to 26.4 V DC
Output
LED
Units manufactured on or after January 5th, 2000
(manufacturing numbers 0510 or later)
Fuse
3.5 A
Output
LED
OUT00
OUT07
COM
A
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to 26.4 V DC
4.5 to 26.4 V DC
OUT00
OUT07
COM
B
OUT08
OUT15
COM
4.5 to 26.4 V DC
4.5 to 26.4 V DC
Output
LED
Ic max. (mA)

Omron CQM1H - 08-2005 Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Omron
Program Capacity	3.2K steps
Model	CQM1H
I/O Points	512 points max
