4-2 Function Mode
4
Functions
1076h
Deceleration time 2
A093
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1077h
A093
(LSB)
R/W
151Bh
2nd deceleration time 2
A293
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
151Ch
A293
(LSB)
R/W
1078h
2-step acceleration/
deceleration selection
A094 R/W
00: Switched via terminal 2CH
01: Switched by setting
⎯
151Dh
2nd 2-step acceleration/
deceleration selection
A294 R/W
107Ah
2-step acceleration
frequency
A095 R/W
0 to 4000 0.1 [Hz]
151Fh
2nd 2-step acceleration
frequency
A295 R/W
107Ch
2-step deceleration
frequency
A096 R/W
0 to 4000 0.1 [Hz]
1521h
*2nd 2-step deceleration
frequency
A296 R/W
107Dh
Acceleration pattern
selection
A097 R/W
00: Line
01: S-shape curve
⎯
107Eh
Deceleration pattern
selection
A098 R/W
00: Line
01: S-shape curve
⎯
1080h OI start frequency A101 R/W 0 to 4000 0.1 [Hz]
1082h OI end frequency A102 R/W 0 to 4000 0.1 [Hz]
1083h OI start ratio A103 R/W 0 to 100 1. [%]
1084h OI end ratio A104 R/W 0 to 100 1. [%]
1085h OI start selection A105 R/W
00: Start frequency A101
01: 0 Hz
⎯
108Eh
Operation frequency input A
setting
A141 R/W
00: Digital Operator (F001)
01: Digital Operator (volume)
02: Input O
03: Input OI
04: RS485 communications
⎯
108Fh
Operation frequency input B
setting
A142 R/W
1090h Operator selection A143 R/W
00: Addition (A + B)
01: Subtraction (A − B)
02: Multiplication (A × B)
⎯
1091h Frequency addition amount A145 R/W 0 to 4000 0.1 [Hz]
1093h Frequency addition direction A146 R/W
00: Adds the A145 value to the output
frequency
01: Subtract A145 value from output
frequency
⎯
1095h VR start frequency A151 R/W 0 to 4000 0.1 [Hz]
1097h VR end frequency A152 R/W 0 to 4000 0.1 [Hz]
1098h VR start ratio A153 R/W 0 to 100 1. [%]
1099h VR end ratio A154 R/W 0 to 100 1. [%]
109Ah VR start selection A155 R/W 0, 1 -
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
