Omron JX - Page 162

4-84
4-2 Function Mode
4
Functions
10A5h Retry selection b001 R/W
00: Alarm
01: 0 Hz start
02: Frequency matching restart
03: Trip after frequency matching
deceleration stop
⎯
10A6h
Allowable momentary power
interruption time
b002 R/W 3 to 250 0.1 [s]
10A7h Retry wait time b003 R/W 3 to 1000 0.1 [s]
10A8h
Momentary power
interruption/undervoltage
trip during stop selection
b004 R/W
00: Disabled
01: Enabled
⎯
10A9h
Momentary power
interruption retry time
selection
b005 R/W
00: 16 times
01: No limit
⎯
1170h
Starting frequency at Active
Frequency Matching restart
b011 R/W
00: Frequency at interruption
01: Max. frequency
02: Set frequency
⎯
10ADh Electronic thermal level b012 R/W
2000 to 10000
Set the rated current to 10000
0.01 [%]
1527h 2nd electronic thermal level b212 R/W
10AEh
Electronic thermal
characteristics selection
b013 R/W
00: Reduced torque characteristics 1
01: Constant torque characteristics
02: Reduced torque characteristics 2
⎯
1528h
2nd electronic thermal
characteristics selection
b213 R/W ⎯
10B5h Overload limit selection b021 R/W 00: Disabled
01: Enabled in acceleration/constant
speed operation
02: Enabled in constant speed operation
⎯
1529h 2nd overload limit selection b221 R/W ⎯
10B6h Overload limit level b022 R/W
2000 to 15000
Set the rated current to 10000
0.01 [%]
152Ah 2nd overload limit level b222 R/W
10B7h Overload limit parameter b023 R/W
1 to 300 0.1 [s]
152Bh 2nd overload limit parameter b223 R/W
10BBh
Overload limit source
selection
b028 R/W
00: Set values in b022
01: Input O terminal
⎯
152Ch
2nd overload limit source
selection
b228 R/W
00: Set values in b222
01: Input O terminal
⎯
1171h
Deceleration rate constant at
Active Frequency Matching
restart
b029 R/W 1 to 30000 0.1 [s]
1172h
Active Frequency Matching
restart level
b030 R/W 200 to 20000 0.01 [%]
10BCh Soft lock selection b031 R/W
00: Data other than b031 cannot be
changed when terminal SFT is ON.
01: Data other than b031 and the
specified frequency parameter
cannot be changed when terminal
SFT is ON.
02: Data other than b031 cannot be
changed.
03: Data other than b031 and the
specified frequency parameter
cannot be changed.
10: Data other than parameters
changeable during operation cannot
be changed.
⎯
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
