Omron JX - Page 163

4-85
4-2 Function Mode
4
Functions
10C9h
Selection of non-stop
function at momentary
power interruption
b050 R/W
00: Disabled
01: Enabled (Stop)
02: Enabled (Restart)
⎯
10CAh
Starting voltage of non-stop
function at momentary
power interruption
b051 R/W 0 to 10000 0.1 [V]
10CBh
Stop deceleration level of
non-stop function at
momentary power
interruption
b052 R/W 0 to 10000 0.1 [V]
10CCh
Deceleration time of non-
stop function at momentary
power interruption
b053 R/W 1 to 30000 0.1 [s]
10CEh
Deceleration starting width
of non-stop function at
momentary power
interruption
b054 R/W 0 to 100 0.1 [Hz]
1173h
Overvoltage protection
proportional gain during
deceleration
b055 R/W 2 to 50 0.1
1174h
Overvoltage protection
integral time during
deceleration
b056 R/W 0 to 1500 0.1 [s]
10CFh AM adjustment b080 R/W 0 to 255 ⎯
10D1h Starting frequency b082 R/W 5 to 99 0.1 [Hz]
10D2h Carrier frequency b083 R/W 20 to 120 0.1 [kHz]
10D3h Initialization selection b084 R/W
00: Clears the trip monitor
01: Initializes data
02: Clears the trip monitor and initializes
data
⎯
10D4h
Initialization parameter
selection
b085 R/W
00: Fixed
*Do not change.
⎯
10D5h
Frequency conversion
coefficient
b086 R/W 1 to 999 0.1
10D6h STOP key selection b087 R/W
00: Enabled
01: Disabled
⎯
10D7h Free-run stop selection b088 R/W
00: 0 Hz start
01: Active Frequency Matching restart
⎯
10D8h Monitor display selection b089 R/W
01: Output frequency monitor
02: Output current monitor
03: Rotation direction monitor
04: PID feedback value monitor
05: Multi-function input monitor
06: Multi-function output monitor
07: Frequency conversion monitor
⎯
10DAh Stop selection b091 R/W
00: Deceleration→Stop
01: Free-run stop
⎯
10DBh Cooling fan control b092 R/W
00: Always ON
01: ON during RUN
02: Depends on the fin temperature
⎯
10F5h
Overvoltage LAD stop
function
b130 R/W
00: Disabled
01: Enabled
⎯
10F6h
Overvoltage LAD stop
function level setting
b131 R/W
200-V class: 330 to 395,
400-V class: 660 to 790
1. [V]
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
