App-17
Appendix-1 Parameter List
Others
C086
AM offset
adjustment
0.0 to 10.0 0.0 Yes V
C091 Not used
Use "00".
*Do not change.
00 ⎯⎯
C101 UP/DWN selection
00: Do not store the frequency data
01: Store the frequency data
00 No ⎯
C102 Reset selection
00: Trip reset at power-on
01: Trip reset when the power is OFF
02: Enabled only during trip (Reset when the
power is ON.)
00 No ⎯
C141
Logic operation
function A input
00: RUN (signal during RUN)
01: FA1 (constant speed arrival signal)
02: FA2 (over set frequency arrival signal)
03: OL (overload warning)
04: OD (excessive PID deviation)
05: AL (alarm output)
06: Dc (disconnection detected)
07: FBV (PID FB status output)
08: NDc (network error)
10: ODc (
Do not use.
)
43: LOC (light load detection signal)
00 No ⎯
C142
Logic operation
function B input
01 No ⎯
C143
Logic operator
selection
00: AND
01: OR
02: XOR
00 No ⎯
C144
Output terminal 11
ON delay
0.0 to 100.0 0.0 No s
C145
Output terminal 11
OFF delay
0.0 to 100.0 0.0 No s
C148
Relay output ON
delay
0.0 to 100.0 0.0 No s
C149
Relay output OFF
delay
0.0 to 100.0 0.0 No s
Control parameter
H003
Motor capacity
selection
200-V class
0.2/0.4/0.75/1.5/2.2/3.7/5.5/7.5
400-V class
0.4/0.75/1.5/2.2/3.7/5.5/7.5
Factory
default
No kW
H203
*2nd motor
capacity selection
Factory
default
H004
Motor pole number
selection
2
4
6
8
4
No Pole
H204
*2nd motor pole
number selection
4
H006
Stabilization
parameter
0. to 255.
100 Yes %
H206
*2nd stabilization
parameter
100 Yes %
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Changes
during
operation
Unit
Set
value
* 2nd control is displayed when SET (08) is allocated to one of from C001 to C005.
