Network Instructions Section 3-25
D: First Destination Word in Remote CPU Unit
Specifies the leading word address of the write destination in the remote CPU
Unit.
C: First Control Word
Specifies the first of five control words (C to C+4).
Operand Specifications
C+2 0
8
111215
07
C0 0
8
111215
07
C+1 0 0
8
111215
07
C+3
15
0
C+4
15
0
FINS unit address of relaying Communications Unit.
• CPU Bus Unit: 10 to 1F hex (unit number + 10 hex)
• Special I/O Unit: 20 to 7F hex (unit number + 20 hex)
Port number of the communications port (logical port)
for the network instruction: 0 to 7 hex
(F hex: Automatic allocation)
Source node address (remote CPU Unit)
(00 to maximum node address (hex))
Example: DeviceNet: 00 to 3F hex (0 to 63)
Write data size (words):
01 to 64 hex (1 to 100 words)
Response monitoring time
0001 to FFFF hex (0.1 to 6553.5 s)
0000 hex: 2 s (default setting)
Explicit message format0000 hex:
DeviceNet (same as using the 2801 FINS command)
Area S D C
CIO Area CIO 0000 to CIO 6143 CIO 0000 to
CIO 6139
Work Area W000 to W511 W000 to W507
Holding Bit Area H000 to H511 H000 to H507
Auxiliary Bit Area A000 to A959 A448 to A959 A000 to A955
Timer Area T0000 to T4095 T0000 to T4091
Counter Area C0000 to C4095 C0000 to C4091
DM Area D00000 to D32767 D00000 to D32763
EM Area without bank E00000 to E32767 E00000 to E32763
EM Area with bank En_00000 to En_32767
(n = 0 to C)
En_00000 to
En_32763
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
