Model Conversion Instructions (Unit Ver. 3.0 or Later) Section 3-35
Examples Specifying a Later Task
When CIO 000000 is ON in the following example, task number 3 is put into
standby status in task number 1. Task number 3 will be not be executed in the
that cycle when program execution reaches task number 3.
Specifying an Earlier Task
When CIO 000000 is ON in the following example, task number 1 is put into
standby status in task number 3. Task number 1 will be not be executed in the
next cycle when program execution reaches task number 1.
3-35 Model Conversion Instructions (Unit Ver. 3.0 or Later)
This section describes instructions used when changing PLC models.
03
Task number 3 is in standby
status in the same cycle,
i.e., it is not executed in the
current or following cycles.
Task 1
Task 3
01
Task number 1 is in standby
status in the next cycle, i.e.,
it is executed in the current
cycle but not in following
cycles.
Task 1
Task 3
Instruction Mnemonic Function code Page
BLOCK TRANSFER XFERC 565 1263
SINGLE WORD DISTRIBUTE DISTC 566 1266
