1177
Other Instructions Section 3-31
Flags
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
---
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
Constants Any constant except 09FF hex, 0A00
to 0AFF hex, or 0D00 to 0E3F hex
---
Data Registers DR0 to DR15 ---
Index Registers --- IR0 to IR15
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to
+2047 ,IR15
DR0 to DR15, IR0 to IR15
---
Area S D
Name Label Operation
Error Flag ER ON if S specifies one of the following PLC memory
addresses that do not exist in the CS/CJ-series:
Temporary Relay (TR) Area (09FF hex)
CPU Bus Link (G) Area (0A00 to 0AFF hex)
SFC Areas (0D00 to 0E3F hex)
OFF in all other cases.
