List of Instructions by Function Code Section 2-4
2-4 List of Instructions by Function Code
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
--- LD LOAD @LD %LD !LD 161
--- LD NOT LOAD NOT --- --- !LD NOT 163
--- AND AND @AND %AND !AND 165
--- AND NOT AND NOT --- --- !AND NOT 167
--- OR OR @OR %OR !OR 169
--- OR NOT OR NOT --- --- !OR NOT 171
--- AND LD AND LOAD --- --- --- 172
--- OR LD OR LOAD --- --- --- 174
--- OUT OUTPUT --- --- !OUT 185
--- OUT NOT OUTPUT NOT --- --- !OUT NOT 187
--- SET SET @SET %SET !SET 195
--- RSET RESET @RSET %RSET !RSET 195
--- TIM HUNDRED-MS TIMER --- --- --- 245
--- CNT COUNTER --- --- --- 275
000 NOP NO OPERATION --- --- --- 207
001 END END --- --- --- 206
002 IL INTERLOCK --- --- --- 210
003 ILC INTERLOCK CLEAR --- --- --- 210
004 JMP JUMP --- --- --- 228
005 JME JUMP END --- --- --- 228
006 FAL FAILURE ALARM @FAL --- --- 1140
007 FALS SEVERE FAILURE
ALARM
--- --- --- 1148
008 STEP STEP DEFINE --- --- --- 909
009 SNXT STEP START --- --- --- 909
010 SFT SHIFT REGISTER --- --- --- 361
011 KEEP KEEP --- --- !KEEP 188
012 CNTR REVERSIBLE
COUNTER
--- --- --- 278
013 DIFU DIFFERENTIATE UP --- --- !DIFU 193
014 DIFD DIFFERENTIATE
DOWN
--- --- !DIFD 193
015 TIMH TEN-MS TIMER --- --- --- 249
016 WSFT WORD SHIFT @WSFT --- --- 368
017 ASFT ASYNCHRONOUS
SHIFT REGISTER
@ASFT --- --- 365
019 MCMP MULTIPLE COMPARE @MCMP --- --- 315
020 CMP UNSIGNED COMPARE --- --- !CMP 303
021 MOV MOVE @MOV --- !MOV 331
022 MVN MOVE NOT @MVN --- --- 333
023 BIN BCD TO BINARY @BIN --- --- 483
024 BCD BINARY TO BCD @BCD --- --- 487
025 ASL ARITHMETIC SHIFT
LEFT
@ASL --- --- 370
026 ASR ARITHMETIC SHIFT
RIGHT
@ASR --- --- 373
027 ROL ROTATE LEFT @ROL --- --- 376
028 ROR ROTATE RIGHT @ROR --- --- 380
029 COM COMPLEMENT @COM --- --- 562
034 ANDW LOGICAL AND @ANDW --- --- 548
035 ORW LOGICAL OR @ORW --- --- 551
036 XORW EXCLUSIVE OR @XORW --- --- 555
