539
Conversion Instructions Section 3-12
Note If the source data is 0, the Equals Flag will turn ON.
If the leftmost bit of the source data is 1, the Negative Flag will turn ON.
Restrictions The following restrictions apply to STR8(602).
â– Restrictions on the CPU Unit
STR8(602) can be used in CPU Units with unit version 4.0 or later only.
â– Restrictions on the CX-Programmer
STR8(602) can be used in CX-Programmer version 7 or higher only.
Flags
3-12-21SIXTEEN-DIGIT NUMBER TO ASCII: STR16(603)
Purpose Converts a 16-digit hexadecimal number (#0000 0000 0000 0000 to
#FFFF FFFF FFFF FFFF) to ASCII data (16 characters).
This instruction is supported by CS/CJ-series CPU Units with unit version 4.0
or later only.
Ladder Symbol
Variations
Applicable Program Areas
1 2 4 3
31 32
33 34
ASCII
5 6 8 7
35 36
37 38
15 8 7 11 12 3 4 0
15 8 7 0
D+1
D+2
D+3
D
Hexadecimal: #12345678
S
S+1
Name Label Operation
Error Flag ER OFF
Equals Flag = ON if the result is 0.
OFF in all other cases.
Negative Flag N ON when the leftmost bit of the source data is 1.
OFF in all other cases.
STR16
S
D
S: Number
D: ASCII text
Variations Executed Each Cycle for ON Condition STR16(603)
Executed Once for Upward Differentiation @STR16(603)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Function block
definitions
Block program
areas
Step program
areas
Subroutines Interrupt
tasks
OK OK OK OK OK
