Table Data Processing Instructions Section 3-17
3-17-11FIND MINIMUM: MIN(183)
Purpose Finds the minimum value in the range.
In CS1D CPU Units for Single-CPU Systems and CS1-H, CJ1-H, and CJ1M
CPU Units, this instruction can be run in the background. Refer to the CS/CJ
Series Programmable Controllers Programming Manual for details on back-
ground execution.
Ladder Symbol
Variations
C: D00100
C+1: D00101
D: D00300
R1:
1
R1
–2
–1
–3
000100CA
100CA
0
0
0
A
10 words
Number of words
Always 0.
1: Outputs address to IR00.
1: Treats data as signed binary.
Decimal
equivalent
Max. value
PC memory
address
MIN(183)
C
R1
D
C: First control word
R1: First word in range
D: Destination word
Variations Executed Each Cycle for ON Condition MIN(183)
Executed Once for Upward Differentiation @MIN(183)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
