Data Control Instructions Section 3-18
3-18-8 SCALING 2: SCL2(486)
Purpose Converts signed binary data into signed BCD data according to the specified
linear function. An offset can be input in defining the linear function.
Ladder Symbol
Variations
Applicable Program Areas
Operands The contents of the three words starting with the first parameter word (P1) are
shown in the following diagram.
Note P1 to P1+2 must be in the same area.
Operand Specifications
SCL2(486)
S
P1
R
S: Source word
P1: First parameter word
R: Result word
Variations Executed Each Cycle for ON Condition SCL2(486)
Executed Once for Upward Differentiation @SCL2(486)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program
areas
Step program
areas
Subroutines Interrupt tasks
OK OK OK OK
∆Y
∆X
P1
P1+1
P1+2
15 0
15 0
15 0
Offset of linear function
8000 to 7FFF (signed binary)
8000 to 7FFF (signed binary)
0000 to 9999 (BCD)
Area S P1 R
CIO Area CIO 0000 to CIO
6143
CIO 0000 to CIO
6141
CIO 0000 to CIO
6143
Work Area W000 to W511 W000 to W509 W000 to W511
Holding Bit Area H000 to H511 H000 to H509 H000 to H511
Auxiliary Bit Area A000 to A959 A000 to A957 A448 to A959
Timer Area T0000 to T4095 T0000 to T4093 T0000 to T4095
Counter Area C0000 to C4095 C0000 to C4093 C0000 to C4095
