347
Data Movement Instructions Section 3-8
3-8-9 BLOCK SET: BSET(071)
Purpose Copies the same word to a range of consecutive words.
Ladder Symbol
Variations
Applicable Program Areas
Operands S: Source Word
Specifies the source data or the word containing the source data.
St: Starting Word
Specifies the first word in the destination range.
E: End Word
Specifies the last word in the destination range.
Note St and E must be in the same data area.
Operand Specifications
BSET(071)
S
E
S: Source word
St: Starting word
E: End word
St
Variations Executed Each Cycle for ON Condition BSET(071)
Executed Once for Upward Differentiation @BSET(071)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
E
E
Source data
to
Destination range
St
St
Area S St E
CIO Area CIO 0000 to CIO 6143
Work Area W000 to W511
Holding Bit Area H000 to H511
Auxiliary Bit Area A000 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D00000 to D32767
To Next Page
