Block Programming Instructions Section 3-32
3-32-7 HUNDRED-MS TIMER WAIT: TIMW(813) and TIMWX(816)
Purpose Delays execution of the rest of the block program until the specified time has
elapsed. Execution will be continued from the next instruction after
TIMW(813)/TIMWX(816) when the timer times out.
Ladder Symbol PV Refresh Method: BCD
PV Refresh Method: Binary
Variations
Applicable Program Areas
Note TIMW(813)/TIMWX(816) must be used in block programming regions even
within subroutines.
Operands N: Timer Number
BCD: 0 to 4095 (decimal)
Binary: 0 to 4095 (decimal)
S: Set Value
BCD: #0000 to #9999 (BCD)
Binary: &0 to &65535 (decimal)
#0000 to #FFFF (hex)
Operand Specifications
TIMW(813) N
SV
N: Timer number
SV: Set value
TIMWX(816) N
SV
N: Timer number
SV: Set value
Variations Always Executed in Block Program
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK Not allowed.
Area N SV
CIO Area --- CIO 0000 to CIO 6143
Work Area --- W000 to W511
Holding Bit Area --- H000 to H511
Auxiliary Bit Area --- A000 to A447
A448 to A959
Timer Area 0000 to 4095 T0000 to T4095
Counter Area --- C0000 to C4095
DM Area --- D00000 to D32767
EM Area without bank --- E00000 to E32767
EM Area with bank --- En_00000 to En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
--- @ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
--- *D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
