Data Movement Instructions Section 3-8
Flags
Note In CS1-H, CJ1-H, CJ1M, and CS1D (for Single-CPU System) CPU Units,
these Flags are left unchanged.
In CS1 and CJ1 CPU Units, these Flags are turned OFF.
Example When CIO 000000 is ON in the following example, the contents of D00100
and D00101 are exchanged with the contents of D00200 and D00201.
3-8-12 SINGLE WORD DISTRIBUTE: DIST(080)
Purpose Transfers the source word to a destination word calculated by adding an offset
value to the base address.
Ladder Symbol
Variations
E2
E1
Buffer
1
st
XFER(070)
operation
2
nd
XFER(070)
operation
3
rd
XFER(070)
operation
Name Label Operation
Error Flag ER Unchanged (See note.)
Equals Flag = Unchanged (See note.)
Negative Flag N Unchanged (See note.)
DIST(080)
S
S: Source word
Bs: Destination base address
Of: Offset
Bs
Of
Variations Executed Each Cycle for ON Condition DIST(080)
Executed Once for Upward Differentiation @DIST(080)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
