Omron SYSMAC CJ - REFERENCE MANUAL 08-2008

483
Conversion Instructions Section 3-12
3-12 Conversion Instructions
This section describes instructions used for data conversion.
3-12-1 BCD TO BINARY: BIN(023)
Purpose Converts BCD data to binary data.
Ladder Symbol
Instruction Mnemonic Function code Page
BCD TO BINARY BIN 023 483
DOUBLE BCD TO DOUBLE
BINARY
BINL 058 485
BINARY TO BCD BCD 024 487
DOUBLE BINARY TO DOUBLE
BCD
BCDL 059 489
2’S COMPLEMENT NEG 160 491
DOUBLE 2’S COMPLEMENT NEGL 161 493
16-BIT TO 32-BIT SIGNED
BINARY
SIGN 600 494
DATA DECODER MLPX 076 496
DATA ENCODER DMPX 077 500
ASCII CONVERT ASC 086 504
ASCII TO HEX HEX 162 508
COLUMN TO LINE LINE 063 512
LINE TO COLUMN COLM 064 514
SIGNED BCD TO BINARY BINS 470 517
DOUBLE SIGNED BCD TO
BINARY
BISL 472 520
SIGNED BINARY TO BCD BCDS 471 523
DOUBLE SIGNED BINARY TO
BCD
BDSL 473 525
GRAY CODE CONVERSION GRY 474 529
FOUR-DIGIT NUMBER TO
ASCII
STR4 601 534
EIGHT-DIGIT NUMBER TO
ASCII
STR8 602 537
SIXTEEN-DIGIT NUMBER TO
ASCII
STR16 603 539
ASCII TO FOUR-DIGIT NUM-
BER
NUM4 604 541
ASCII TO EIGHT-DIGIT NUM-
BER
NUM8 605 544
ASCII TO SIXTEEN-DIGIT
NUMBER
NUM16 606 545
BIN(023)
S
R
S: Source word
R: Result word
