538
Conversion Instructions Section 3-12
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
Description STR8(602) converts the numerical data in S and S+1 (8-digit hexadecimal,
#0000 0000 to #FFFF FFFF) to ASCII data (8 characters) and writes the
result to D, D+1, D+2, and D+3.
STR8
S
D
S: Number
D: ASCII text
Variations Executed Each Cycle for ON Condition STR8(602)
Executed Once for Upward Differentiation @STR8(602)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Function block
definitions
Block program
areas
Step program
areas
Subroutines Interrupt
tasks
OK OK OK OK OK
Area S D
CIO Area CIO 0000 to CIO 6142 CIO 0000 to CIO 6140
Work Area W000 to W510 W000 to W508
Holding Bit Area H000 to H510 H000 to H508
Auxiliary Bit Area A448 to A958 A448 to A956
Timer Area T0000 to T4094 T0000 to T4092
Counter Area C0000 to C4094 C0000 to C4092
DM Area D00000 to D32766 D00000 to D32764
EM Area without bank E00000 to E32766 E00000 to E32764
EM Area with bank En_00000 to En_32766
(n = 0 to C)
En_00000 to En_32764
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #0000 0000 to #FFFF FFFF ---
Data Registers --- ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
