1124
Clock Instructions Section 3-28
R through R+2: Result Data
R through R+2 contain the result of the addition. R through R+2 must be in the
same data area.
Operand Specifications
15 8 07
R
15 8 07
R+1
15 8 07
R+2
Seconds: 00 to 59 (BCD)
Minutes: 00 to 59 (BCD)
Hour: 00 to 23 (BCD)
Day: 01 to 31 (BCD)
Month: 01 to 12 (BCD)
Year: 00 to 99 (BCD)
Area C T R
CIO Area CIO 0000 to
CIO 6141
CIO 0000 to
CIO 6142
CIO 0000 to
CIO 6141
Work Area W000 to W509 W000 to W510 W000 to W509
Holding Bit Area H000 to H509 H000 to H510 H000 to H509
Auxiliary Bit Area A000 to A957 A000 to A958 A448 to A957
Timer Area T0000 to T4093 T0000 to T4094 T0000 to T4093
Counter Area C0000 to C4093 C0000 to C4094 C0000 to C4093
DM Area D00000 to
D32765
D00000 to
D32766
D00000 to
D32765
EM Area without bank E00000 to
E32765
E00000 to
E32766
E00000 to
E32765
EM Area with bank En_00000 to
En_32765
(n = 0 to C)
En_00000 to
En_32766
(n = 0 to C)
En_00000 to
3En_2765
(n = 0 to C)
Indirect DM/EM
addresses in binary
@D00000 to @D32767
@E00000 to @E32767
@En_00000 to @En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants --- Specified values
only
---
Data Registers ---
