80
Instruction Functions Section 2-2
DEAD ZONE
CONTROL
ZONE
@ZONE
682
Output
Required
784
TIME-PROPOR-
TIONAL OUTPUT
TPO
685
(CS/CJ-series
Unit Ver. 2.0 or
later only)
Inputs the duty ratio or manipulated variable from the specified word,
converts the duty ratio to a time-proportional output based on the spec-
ified parameters, and outputs the result from the specified output.
Output
Required
787
SCALING
SCL
@SCL
194
Output
Required
795
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
ZONE(682)
S
C
D
S: Input word
C: 1st limit word
D: Output word
Output
Input
Adds the specified bias to input data and outputs the result.
Positive bias (C+1)
Negative bias (C)
TPO (685)
S
C
R
S: Input word
C: 1st parameter
word
R: Pulse Output
Bit
SCL(194)
S
P1
R
S: Source word
P1: 1st parameter
word
R: Result word
(BCD)
(BIN)
(BCD)
(BIN)
P
P1 + 1
P1 + 2
P1 + 3
R (unsigned BCD)
Converts unsigned binary data into unsigned BCD data according to
the specified linear function.
Scaling is performed according
to the linear function defined by
points A and B.
Point B
Point A
Converted
value
Converted
value
S (unsigned binary)
To Next Page
