1238
Text String Processing Instructions Section 3-33
Operands S1: Text String
S2: Replacement Text String
S3: Number of Characters (0000 to 0FFF hex or &0 to &4095)
S4: Beginning Position (0001 to 0FFF hex or &0 to &4095)
Note 1. The data from S1 to S1 + the maximum 2,047 words, from S2 to S2 + the
maximum 2,047 words, and from D to D + the maximum 2,047 words must
be in the same area.
2. The data from D to D + the maximum 2,047 words and from either S1 to
S1 + the maximum 2,047 words or from S2 to S2 + the maximum 2,047
words can overlap.
Operand Specifications
15 0
S1
to
Text string data: 4,095 characters max. + NUL
S1 + maximum 2,047 words
15 0
S2
to
Text string data: 4,095 characters max. + NUL
S2 + maximum 2,047 words
15 0
D
to
Text string data: 4,095 characters max. + NUL
S2 + maximum 2,047 words
Area S1 S2 S3 S4 D
CIO Area CIO 0000 to CIO 6143
Work Area W000 to W511
Holding Bit Area H000 to H511
Auxiliary Bit Area A000 to A447
A448 to A959
A448 to
A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D00000 to D32767
EM Area without bank E00000 to E32767
EM Area with bank En_00000 to En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
To Next Page
