Instruction Functions Section 2-2
HEXADECIMAL
KEY INPUT
HKY
212
(CS/CJ-series
CPU Unit Ver. 2.0
or later only)
Reads numeric data from a hexadecimal keypad connected to an Input
Unit and Output Unit and stores up to 8 digits of hexadecimal data in
the specified words.
Output
Required
948
MATRIX INPUT
MTR
213
(CS/CJ-series
CPU Unit Ver. 2.0
or later only)
Inputs up to 64 signals from an 8
× 8 matrix connected to an Input Unit
and Output Unit (using 8 input points and 8 output points) and stores
that 64-bit data in the 4 destination words.
Output
Required
953
7-SEGMENT DIS-
PLAY OUTPUT
7SEG
214
(CS/CJ-series
CPU Unit Ver. 2.0
or later only)
Converts the source data (either 4-digit or 8-digit BCD) to 7-segment
display data, and outputs that data to the specified output word.
Output
Required
957
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
HKY (212)
I
O
D
C
I: Data input
word
O: Output word
D: 1st register
word
C: System word
MTR (213)
I
O
D
C
I: Data input
word
O: Output word
D: 1st
destination
word
C: System word
7SEG (214)
S
O
C
D
S: 1st source
word
O: Output word
C: Control data
D: S
y
stem word
