1295
CS-series Instruction Execution Times and Number of Steps Section 4-1
4-1-10 Conversion Instructions
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
BCD TO
BINARY
BIN 023 3 0.22 0.24 0.25 0.29 ---
DOUBLE
BCD TO
DOUBLE
BINARY
BINL 058 3 6.5 6.8 9.1 9.1 ---
BINARY TO
BCD
BCD 024 3 0.24 0.26 8.3 8.3 ---
DOUBLE
BINARY TO
DOUBLE
BCD
BCDL 059 3 6.7 7.0 9.2 9.2 ---
2’S COM-
PLEMENT
NEG 160 3 0.18 0.20 0.25 0.29 ---
DOUBLE
2’S COM-
PLEMENT
NEGL 161 3 0.32 0.34 0.42 0.5 ---
16-BIT TO
32-BIT
SIGNED
BINARY
SIGN 600 3 0.32 0.34 0.42 0.50 ---
DATA
DECODER
MLPX 076 4 0.32 0.42 8.8 8.8 Decoding 1 digit
(4 to 16)
0.98 1.20 12.8 12.8 Decoding 4 dig-
its (4 to 16)
3.30 4.00 20.3 20.3 Decoding 1 digit
(8 to 256)
6.50 7.90 33.4 33.4 Decoding 2 dig-
its (8 to 256)
DATA
ENCODER
DMPX 077 4 7.5 7.9 10.4 10.4 Encoding 1 digit
(16 to 4)
49.6 50.2 59.1 59.1 Encoding 4 dig-
its (16 to 4)
18.2 18.6 23.6 23.6 Encoding 1 digit
(256 to 8)
55.1 57.4 92.5 92.5 Encoding 2 dig-
its (256 to 8)
ASCII CON-
VERT
ASC 086 4 6.8 7.1 9.7 9.7 Converting 1
digit into ASCII
11.2 11.7 15.1 15.1 Converting 4
digits into ASCII
ASCII TO
HEX
HEX 162 4 7.1 7.4 10.1 10.1 Converting 1
digit
COLUMN
TO LINE
LINE 063 4 19.0 23.1 29.1 29.1 ---
LINE TO
COLUMN
COLM 064 4 23.2 27.5 37.3 37.3 ---
