Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 - Page 1337

1297
CS-series Instruction Execution Times and Number of Steps Section 4-1
Note 1. When a double-length operand is used, add 1 to the value shown in the
length column in the following table.
2. Supported only by CPU Units Ver. 2.0 or later.
4-1-11 Logic Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
ASCII TO
FOUR-
DIGIT NUM-
BER
NUM4 604 3 18.46 27.27 --- ---
ASCII TO
EIGHT-
DIGIT NUM-
BER
NUM8 605 3 18.46 27.27 --- ---
ASCII TO
SIXTEEN-
DIGIT NUM-
BER
NUM16 606 3 52.31 78.25 --- ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
LOGICAL
AND
ANDW 034 4 0.18 0.20 0.25 0.37 ---
DOUBLE
LOGICAL
AND
ANDL 610 4 0.32 0.34 0.42 0.54 ---
LOGICAL OR ORW 035 4 0.22 0.32 0.25 0.37 ---
DOUBLE
LOGICAL OR
ORWL 611 4 0.32 0.34 0.42 0.54 ---
EXCLUSIVE
OR
XORW 036 4 0.22 0.32 0.25 0.37 ---
DOUBLE
EXCLUSIVE
OR
XORL 612 4 0.32 0.34 0.42 0.54 ---
EXCLUSIVE
NOR
XNRW 037 4 0.22 0.32 0.25 0.37 ---
DOUBLE
EXCLUSIVE
NOR
XNRL 613 4 0.32 0.34 0.42 0.54 ---
COMPLE-
MENT
COM 029 2 0.22 0.32 0.29 0.37 ---
DOUBLE
COMPLE-
MENT
COML 614 2 0.40 0.56 0.50 0.67 ---
