1300
CS-series Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
16-BIT
BINARY TO
DOUBLE
FLOATING
DBL 843 3 9.9 10.0 --- --- ---
32-BIT
BINARY TO
DOUBLE
FLOATING
DBLL 844 3 9.8 10.0 --- --- ---
DOUBLE
FLOATING-
POINT ADD
+D 845 4 11.2 11.9 --- --- ---
DOUBLE
FLOATING-
POINT SUB-
TRACT
−D 846 4 11.2 11.9 --- --- ---
DOUBLE
FLOATING-
POINT MULTI-
PLY
*D 847 4 12.0 12.7 --- --- ---
DOUBLE
FLOATING-
POINT
DIVIDE
/D 848 4 23.5 24.2 --- --- ---
DOUBLE
DEGREES TO
RADIANS
RADD 849 3 27.4 27.8 --- --- ---
DOUBLE
RADIANS TO
DEGREES
DEGD 850 3 11.2 11.9 --- --- ---
DOUBLE
SINE
SIND 851 3 45.4 45.8 --- --- ---
DOUBLE
COSINE
COSD 852 3 43.0 43.4 --- --- ---
DOUBLE
TAN GE NT
TAND 853 3 20.1 20.5 --- --- ---
DOUBLE ARC
SINE
ASIND 854 3 21.5 21.9 --- --- ---
DOUBLE ARC
COSINE
ACOSD 855 3 24.7 25.1 --- --- ---
DOUBLE ARC
TAN GE NT
ATAND 856 3 19.3 19.7 --- --- ---
DOUBLE
SQUARE
ROOT
SQRTD 857 3 47.4 47.9 --- --- ---
DOUBLE
EXPONENT
EXPD 858 3 121.0 121.4 --- --- ---
DOUBLE
LOGARITHM
LOGD 859 3 16.0 16.4 --- --- ---
DOUBLE
EXPONEN-
TIAL POWER
PWRD 860 4 223.9 224.2 --- --- ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
