1306
CS-series Instruction Execution Times and Number of Steps Section 4-1
Note 1. When a double-length operand is used, add 1 to the value shown in the
length column in the following table.
2. Supported only by CPU Units Ver. 2.0 or later.
4-1-23 File Memory Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
4-1-24 Display Instructions
EXPLICIT
MESSAGE
SEND
(See note 2.)
EXPLT 720 4 127.6 190.0 --- --- ---
EXPLICIT
GET
ATTRIBUTE
(See note 2.)
EGATR 721 4 123.9 185.0 --- --- ---
EXPLICIT
SET
ATTRIBUTE
(See note 2.)
ESATR 722 3 110.0 164.4 --- --- ---
EXPLICIT
WORD
READ
(See note 2.)
ECHRD 723 4 106.8 158.9 --- --- ---
EXPLICIT
WORD
WRITE
(See note 2.)
ECHWR 724 4 106.0 158.3 --- --- ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
READ DATA
FILE
FREAD 700 5 391.4 632.4 684.1 684.1 2-character
directory + file
name in binary
836.1 1.33 ms 1.35 ms 1.35 ms 73-character
directory + file
name in binary
WRITE
DATA FILE
FWRIT 701 5 387.8 627.0 684.7 684.7 2-character
directory + file
name in binary
833.3 1.32 ms 1.36 ms 1.36 ms 73-character
directory + file
name in binary
WRITE
TEXT FILE
TWRIT 704 5 390.1 619.1 --- ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
DISPLAY
MESSAGE
MSG 046 3 10.1 14.2 14.3 14.3 Displaying mes-
sage
8.4 11.3 11.3 11.3 Deleting dis-
played message
