Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 - Page 1362

1322
CJ-series Instruction Execution Times and Number of Steps Section 4-2
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
ROTATE
LEFT
ROL 27 2 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
ROTATE
LEFT
ROLL 572 2 0.32 0.40 0.56 0.67 0.80 0.80 ---
ROTATE
LEFT WITH-
OUT
CARRY
RLNC 574 2 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
ROTATE
LEFT WITH-
OUT
CARRY
RLNL 576 2 0.32 0.40 0.56 0.67 0.80 0.80 ---
ROTATE
RIGHT
ROR 28 2 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
ROTATE
RIGHT
RORL 573 2 0.32 0.40 0.56 0.67 0.80 0.80 ---
ROTATE
RIGHT
WITHOUT
CARRY
RRNC 575 2 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
ROTATE
RIGHT
WITHOUT
CARRY
RRNL 577 2 0.32 0.40 0.56 0.67 0.80 0.80 ---
ONE DIGIT
SHIFT LEFT
SLD 74 3 5.9 5.9 6.1 8.2 7.6 12.95 Shifting 1 word
561.1 561.1 626.3 760.7 1.15 ms 1.27 ms Shifting 1,000
words
ONE DIGIT
SHIFT
RIGHT
SRD 75 3 6.9 6.9 7.1 8.7 8.6 15.00 Shifting 1 word
760.5 760.5 895.5 1.07 ms 1.72 ms 1.82 ms Shifting 1,000
words
SHIFT N-BIT
DATA LEFT
NSFL 578 4 7.5 7.5 8.3 10.5 14.8 16.0 Shifting 1 bit
34.5 40.3 45.4 55.5 86.7 91.3 Shifting 1,000 bits
SHIFT N-BIT
DATA RIGHT
NSFR 579 4 7.5 7.5 8.3 10.5 14.7 15.9 Shifting 1 bit
48.2 50.5 55.3 69.3 114.1 119.6 Shifting 1,000 bits
SHIFT N-
BITS LEFT
NASL 580 3 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
SHIFT N-
BITS LEFT
NSLL 582 3 0.32 0.40 0.56 0.67 0.80 0.80 ---
SHIFT N-
BITS RIGHT
NASR 581 3 0.18 0.22 0.32 0.37 0.45 0.45 ---
DOUBLE
SHIFT N-
BITS RIGHT
NSRL 583 3 0.32 0.40 0.56 0.67 0.80 0.80 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11/
21
CJ1M
CPU11/
21
