Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 - Page 1364

1324
CJ-series Instruction Execution Times and Number of Steps Section 4-2
DOUBLE BCD
ADD WITH-
OUT CARRY
+BL 405 4 9.2 13.3 14.5 19.0 24.4 27.7 ---
BCD ADD
WITH CARRY
+BC 406 4 8.0 8.9 9.1 14.5 19.7 22.6 ---
DOUBLE BCD
ADD WITH
CARRY
+BCL 407 4 9.6 13.8 15.0 19.6 25.2 28.8 ---
SIGNED
BINARY SUB-
TRACT WITH-
OUT CARRY
– 410 4 0.18 0.18 0.20 0.37 0.3 0.3 ---
DOUBLE
SIGNED
BINARY SUB-
TRACT WITH-
OUT CARRY
–L 411 4 0.18 0.32 0.34 0.54 0.60 0.60 ---
SIGNED
BINARY SUB-
TRACT WITH
CARRY
–C 412 4 0.18 0.18 0.20 0.37 0.3 0.3 ---
DOUBLE
SIGNED
BINARY SUB-
TRACT WITH
CARRY
–CL 413 4 0.18 0.32 0.34 0.54 0.60 0.60 ---
BCD SUB-
TRACT WITH-
OUT CARRY
–B 414 4 7.4 8.0 8.2 13.1 18.1 20.5 ---
DOUBLE BCD
SUBTRACT
WITHOUT
CARRY
–BL 415 4 8.9 12.8 14.0 18.2 23.2 26.7 ---
BCD SUB-
TRACT WITH
CARRY
–BC 416 4 7.9 8.5 8.6 13.8 19.1 21.6 ---
DOUBLE BCD
SUBTRACT
WITH CARRY
–BCL 417 4 9.4 13.4 14.7 18.8 24.3 27.7 ---
SIGNED
BINARY MUL-
TIPLY
* 420 4 0.26 0.38 0.40 0.58 0.65 0.65 ---
DOUBLE
SIGNED
BINARY MUL-
TIPLY
*L 421 4 5.93 7.23 8.45 11.19 13.17 15.0 ---
UNSIGNED
BINARY MUL-
TIPLY
*U 422 4 0.26 0.38 0.40 0.58 0.75 0.75 ---
DOUBLE
UNSIGNED
BINARY MUL-
TIPLY
*UL 423 4 5.9 7.1 8.3 10.63 13.30 15.2 ---
BCD MULTI-
PLY
*B 424 4 8.3 9.0 9.2 12.8 17.5 19.7 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11
/21
CJ1M
CPU11
/21
