CJ-series Instruction Execution Times and Number of Steps Section 4-2
DATA
DECODER
MLPX 076 4 0.32 0.32 0.42 8.8 0.85 0.85 Decoding 1 digit (4
to 16)
0.98 0.98 1.20 12.8 1.60 1.60 Decoding 4 digits
(4 to 16)
3.30 3.30 4.00 20.3 4.70 4.70 Decoding 1 digit (8
to 256)
6.50 6.50 7.90 33.4 8.70 8.70 Decoding 2 digits
(8 to 256)
DATA
ENCODER
DMPX 077 4 7.5 7.5 7.9 10.4 9.4 13.9 Encoding 1 digit
(16 to 4)
49.6 49.6 50.2 59.1 57.3 71.73 Encoding 4 digits
(16 to 4)
18.2 18.2 18.6 23.6 56.8 82.7 Encoding 1 digit
(256 to 8)
55.1 55.1 57.4 92.5 100.0 150.7 Encoding 2 digits
(256 to 8)
ASCII CON-
VERT
ASC 086 4 6.8 6.8 7.1 9.7 8.3 14.6 Converting 1 digit
into ASCII
9.0 11.2 11.7 15.1 19.1 21.8 Converting 4 digits
into ASCII
ASCII TO
HEX
HEX 162 4 7.1 7.1 7.4 10.1 12.1 15.6 Converting 1 digit
COLUMN
TO LINE
LINE 063 4 16.6 19.0 23.1 29.1 37.0 40.3 ---
LINE TO
COLUMN
COLM 064 4 18.4 23.2 27.5 37.3 45.7 48.2 ---
SIGNED
BCD TO
BINARY
BINS 470 4 6.8 8.0 8.3 12.1 16.2 17.0 Data format
setting No. 0
6.8 8.0 8.3 12.1 16.2 17.1 Data format
setting No. 1
7.1 8.3 8.6 12.7 16.5 17.7 Data format
setting No. 2
7.4 8.5 8.8 13.0 16.5 17.6 Data format
setting No. 3
DOUBLE
SIGNED
BCD TO
BINARY
BISL 472 4 6.9 9.2 9.6 13.6 18.4 19.6 Data format
setting No. 0
7.0 9.2 9.6 13.7 18.5 19.8 Data format
setting No. 1
7.3 9.5 9.9 14.2 18.6 20.1 Data format
setting No. 2
7.6 9.6 10.0 14.4 18.7 20.1 Data format
setting No. 3
SIGNED
BINARY TO
BCD
BCDS 471 4 6.6 6.6 6.9 10.6 13.5 16.4 Data format
setting No. 0
6.7 6.7 7.0 10.8 13.8 16.7 Data format
setting No. 1
6.8 6.8 7.1 10.9 13.9 16.8 Data format
setting No. 2
7.1 7.2 7.5 11.5 14.0 17.1 Data format
setting No. 3
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
