CJ-series Instruction Execution Times and Number of Steps Section 4-2
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
4-2-15 Table Data Processing Instructions
DOUBLE TAN-
GENT
TAND 853 3 19.8 20.1 20.5 --- 97.9 157.0 ---
DOUBLE ARC
SINE
ASIND 854 3 21.5 21.5 21.9 --- 32.3 37.3 ---
DOUBLE ARC
COSINE
ACOSD 855 3 24.7 24.7 25.1 --- 29.9 42.5 ---
DOUBLE ARC
TAN GE NT
ATAND 856 3 19.3 19.3 19.7 --- 24.0 34.4 ---
DOUBLE
SQUARE
ROOT
SQRTD 857 3 47.4 47.4 47.9 --- 52.9 81.9 ---
DOUBLE
EXPONENT
EXPD 858 3 121.0 121.0 121.4 --- 126.3 201.3 ---
DOUBLE
LOGARITHM
LOGD 859 3 16.0 16.0 16.4 --- 21.6 29.3 ---
DOUBLE
EXPONEN-
TIAL POWER
PWRD 860 4 223.9 223.9 224.2 --- 232.3 373.4 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11
/21
CJ1M
CPU11
/21
SET STACK SSET 630 3 8.0 8.0 8.3 8.5 14.2 20.3 Designating 5
words in stack
area
231.6 231.6 251.8 276.8 426.5 435.3 Designating
1,000 words in
stack area
PUSH ONTO
STACK
PUSH 632 3 6.5 6.5 8.6 9.1 15.7 16.4 ---
FIRST IN
FIRST OUT
FIFO 633 3 6.9 6.9 8.9 10.6 15.8 16.8 Designating 5
words in stack
area
352.6 352.6 434.3 1.13
ms
728.0 732.0 Designating
1,000 words in
stack area
LAST IN
FIRST OUT
LIFO 634 3 7.0 7.0 9.0 9.9 16.6 17.2 ---
DIMENSION
RECORD
TABLE
DIM 631 5 15.2 15.2 21.6 142.1 27.8 27.1 ---
SET RECORD
LOCATION
SETR 635 4 5.4 5.4 5.9 7.0 12.8 13.2 ---
GET RECORD
NUMBER
GETR 636 4 7.8 7.8 8.4 11.0 16.1 18.3 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6
@H-R
CPU6
@H
CPU4
@H
CPU4
@
CJ1M
exclud-
ing
CPU11/
21
CJ1M
CPU11
/21
