Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 - Page 156

116
Alphabetical List of Instructions by Mnemonic Section 2-3
B
C
ASLL DOUBLE SHIFT LEFT 570 @ASLL --- --- 371
ASR ARITHMETIC SHIFT
RIGHT
026 @ASR --- --- 373
ASRL DOUBLE SHIFT
RIGHT
571 @ASRL --- --- 374
ATAN ARC TANGENT 465 @ATAN --- --- 627
ATAND DOUBLE ARC TAN-
GENT
856 @ATAND --- --- 684
AVG AVERAGE 195 --- --- --- 807
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
BAND DEAD BAND CON-
TROL
681 @BAND --- --- 781
BCD BINARY TO BCD 024 @BCD --- --- 487
BCDL DOUBLE BINARY TO
BCD
059 @BCDL --- --- 489
BCDS SIGNED BINARY TO
BCD
471 @BCDS --- --- 523
BCMP UNSIGNED BLOCK
COMPARE
068 @BCMP --- --- 320
BCMP2 EXPANDED BLOCK
COMPARE
502 @BCMP2 --- --- 322
BCNT BIT COUNTER 067 @BCNT --- --- 587
BCNTC BIT COUNTER 621 @BCNTC --- --- 1275
BDSL DOUBLE SIGNED
BINARY TO BCD
473 @BDSL --- --- 525
BEND BLOCK PROGRAM
END
801 --- --- --- 1191
BIN BCD TO BINARY 023 @BIN --- --- 483
BINL DOUBLE BCD TO
DOUBLE BINARY
058 @BINL --- --- 485
BINS SIGNED BCD TO
BINARY
470 @BINS --- --- 517
BISL DOUBLE SIGNED
BCD TO BINARY
472 @BISL --- --- 520
BPPS BLOCK PROGRAM
PAUSE
811 --- --- --- 1193
BPRG BLOCK PROGRAM
BEGIN
096 --- --- --- 1191
BPRS BLOCK PROGRAM
RESTART
812 --- --- --- 1193
BREAK BREAK LOOP 514 --- --- --- 241
BSET BLOCK SET 071 @BSET --- --- 347
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
CADD CALENDAR ADD 730 @CADD --- --- 1122
CCL LOAD CONDITION
FLAGS
283 @CCL --- --- 1173
CCS SAVE CONDITION
FLAGS
282 @CCS --- --- 1171
CJP CONDITIONAL JUMP 510 --- --- --- 232
CJPN CONDITIONAL JUMP 511 --- --- --- 232
CLC CLEAR CARRY 041 @CLC --- --- 1166
Mnemonic Instruction Function code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
