Omron SYSMAC CJ - REFERENCE MANUAL 08-2008

129
Alphabetical List of Instructions by Mnemonic Section 2-3
Z
Symbols
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
ZCP AREA RANGE COM-
PARE
088 --- --- --- 326
ZCPL DOUBLE AREA
RANGE COMPARE
116 --- --- --- 329
ZONE DEAD ZONE
CONTROL
682 @ZONE --- --- 784
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
7SEG 7-SEGMENT DISPLAY
OUTPUT
214 --- --- --- 957
+ SIGNED BINARY ADD
WITHOUT CARRY
400 @+ --- --- 426
+$ CONCATENATE
STRING
656 @+$ --- --- 1223
++ INCREMENT BINARY 590 @++ --- --- 409
++B INCREMENT BCD 594 @++B --- --- 417
++BL DOUBLE
INCREMENT BCD
595 @++BL --- --- 419
++L DOUBLE
INCREMENT BINARY
591 @++L --- --- 411
+B BCD ADD WITHOUT
CARRY
404 @+B --- --- 434
+BC BCD ADD WITH
CARRY
406 @+BC --- --- 437
+BCL DOUBLE BCD ADD
WITH CARRY
407 @+BCL --- --- 439
+BL DOUBLE BCD ADD
WITHOUT CARRY
405 @+BL --- --- 435
+C SIGNED BINARY ADD
WITH CARRY
402 @+C --- --- 430
+CL DOUBLE SIGNED
BINARY ADD WITH
CARRY
403 @+CL --- --- 432
+D DOUBLE FLOATING-
POINT ADD
845 @+D --- --- 663
+F FLOATING-POINT
ADD
454 @+F --- --- 601
+L DOUBLE SIGNED
BINARY ADD
WITHOUT CARRY
401 @+L --- --- 428
– SIGNED BINARY
SUBTRACT
WITHOUT CARRY
410 @– --- --- 440
– – DECREMENT BINARY 592 @– – --- --- 413
– –B DECREMENT BCD 596 @– –B --- --- 421
– –BL DOUBLE
DECREMENT BCD
597 @– –BL --- --- 423
– –L DOUBLE
DECREMENT BINARY
593 @– –L --- --- 415
–B BCD SUBTRACT
WITHOUT CARRY
414 @–B --- --- 451
–BC BCD SUBTRACT
WITH CARRY
416 @–BC --- --- 456
–BCL DOUBLE BCD
SUBTRACT WITH
CARRY
417 @–BCL --- --- 457
