186
Sequence Output Instructions Section 3-4
Applicable Program Areas
Operand Specifications
Description If there is no immediate refreshing specification, the status of the execution
condition (power flow) is written to the specified bit in I/O memory. If there is
an immediate refreshing specification, the status of the execution condition
(power flow) is also written to the Basic Output Unit’s output terminal in addi-
tion to the output bit in I/O memory.
Flags There are no flags affected by this instruction.
Precautions Immediate refreshing (!) can be specified for OUT and OUT NOT. An immedi-
ate refresh instruction updates the status of the output terminal just after the
instruction is executed for the Basic Output Unit (but not for Basic Output
Units on Slave Racks or for C200H Group 2 Multi-point Input Units), at the
same time as it writes the status of the execution condition (power flow) to the
specified output bit in I/O memory.
OUT cannot be used for addresses in the DM and EM Areas. Use OUTB(534)
instead.
Block program areas Step program areas Subroutines Interrupt tasks
Not allowed OK OK OK
Area OUT bit operand
CIO Area CIO 000000 to CIO 614315
Work Area W00000 to W51115
Holding Bit Area H00000 to H51115
Auxiliary Bit Area A44800 to A95915
Timer Area ---
Counter Area ---
TR Area TR0 to TR15
DM Area ---
EM Area without bank ---
EM Area with bank ---
Indirect DM/EM
addresses in binary
---
Indirect DM/EM
addresses in BCD
---
Constants ---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to ,IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
