Sequence Output Instructions Section 3-4
Note The bits being turned ON or OFF must be in the same data area. (The range
of words is roughly D to D+N2
÷16.)
Operand Specifications
Description The operation of SETA(530) and RSTA(531) are described separately below.
Operation of SETA(530)
SETA(530) turns ON N2 bits, beginning from bit N1 of D, and continuing to the
left (more-significant bits). All other bits are left unchanged. (No changes will
be made if N2 is set to 0.)
Bits turned ON by SETA(530) can be turned OFF by any other instructions,
not just RSTA(531).
D
to
Area D N1 N2
CIO Area CIO 0000 to CIO 6143
Work Area W000 to W511
Holding Bit Area H000 to H511
Auxiliary Bit Area A448 to A959 A000 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D00000 to D32767
EM Area without bank E00000 to E32767
EM Area with bank En_00000 to En_32767
(n = 0 to C)
Indirect DM/EM addresses in
binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM addresses in
BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants --- #0000 to #000F
(binary) or &0 to
&15
#0000 to #FFFF
(binary) or &0 to
&65535
Data Registers --- DR0 to DR15
Index Registers ---
Indirect addressing using
Index Registers
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –) IR0 to, –(– –) IR15
