NSJ Series
NSJ5-TQ@@(B)-G5D, NSJ5-SQ@@(B)-G5D,
NSJ8-TV@@(B)-G5D, NSJ10-TV@@(B)-G5D,
NSJ12-TS@@(B)-G5D
Operation Manual
W452 Provides the following information about the NSJ-
series NSJ Controllers:
Overview and features
Designing the system configuration
Installation and wiring
I/O memory allocations
Troubleshooting and maintenance
Use this manual in combination with the following
manuals: SYSMAC CS Series Operation Manual
(W339), SYSMAC CJ Series Operation Manual
(W393), SYSMAC CS/CJ Series Programming
Manual (W394), and NS-V1/-V2 Series Setup
Manual (V083)
SYSMAC WS02-CX
@@-V@
CX-Programmer Operation Manual
W446 Provides information on how to use the CX-Pro-
grammer for all functionality except for function
blocks.
SYSMAC WS02-CX
@@-V@
CX-Programmer Ver. 7.0 Operation Manual
Function Blocks
(CS1G-CPU
@@H, CS1H-CPU@@H,
CJ1G-CPU@@H, CJ1H-CPU@@H,
CJ1M-CPU@@, CP1H-X@@@@-@,
CP1H-XA
@@@@-@, CP1H-Y@@@@-@
CPU Units)
W447 Describes the functionality unique to the CX-Pro-
grammer and CP-series CPU Units or CS/CJ-
series CPU Units with unit version 3.0 or later
based on function blocks. Functionality that is the
same as that of the CX-Programmer is described
in W446 (enclosed).
SYSMAC CS/CJ Series
CS1W-SCB
@@-V1, CS1W-SCU@@-V1,
CJ1W-SCU
@@-V1
Serial Communications Boards/Units Operation Manual
W336 Describes the use of Serial Communications Unit
and Boards to perform serial communications
with external devices, including the usage of stan-
dard system protocols for OMRON products.
SYSMAC WS02-PSTC1-E
CX-Protocol Operation Manual
W344 Describes the use of the CX-Protocol to create
protocol macros as communications sequences
to communicate with external devices.
CXONE-AL@@C-V3/AL@@D-V3
CX-Integrator Operation Manual
W464 Describes operating procedures for the CX-Inte-
grator Network Configuration Tool for CS-, CJ-,
CP-, and NSJ-series Controllers.
CXONE-AL@@C-V3/AL@@D-V3
CX-One Setup Manual
W463 Installation and overview of CX-One FA Inte-
grated Tool Package.
Name Cat. No. Contents
!WARNING Failure to read and understand the information provided in this manual may result in per-
sonal injury or death, damage to the product, or product failure. Please read each section
in its entirety and be sure you understand the information provided in the section and
related sections before attempting any of the procedures or operations given.
To Next Page
