Sequence Control Instructions Section 3-5
Applicable Program Areas
Operands N: Jump Number
The jump number must be 0000 to 03FF (0 to 1,023 decimal).
Note For CJ1M-CPU11 and CJ1M-CPU21 CPU Units, the jump number must be
between the range 0000 to 00FF hex or &0 to &255 decimal.
Operand Specifications
Note For CJ1M-CPU11 and CJ1M-CPU21 CPU Units, the range is #0000 to #00FF
(binary) or &0 to &1023 (decimal).
Description The operation of CJP(510) and CJPN(511) differs only in the execution condi-
tion. CJP(510) jumps to the first JME(005) when the execution condition is ON
Variations Jumps when OFF/Does Not Jump when ON CJPN(511)
Immediate Refreshing Specification Not supported
Variations Executed Each Cycle for ON Condition JME(005)
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK Not allowed OK OK
Area N
CJP(510) CJPN(511) JME(005)
CIO Area CIO 0000 to CIO 6143 ---
Work Area W000 to W511 ---
Holding Bit Area H000 to H511 ---
Auxiliary Bit Area A000 to A959 ---
Timer Area T0000 to T4095 ---
Counter Area C0000 to C4095 ---
DM Area D00000 to D32767 ---
EM Area without
bank
E00000 to E32767 ---
EM Area with bank En_00000 to En_32767
(n = 0 to C)
---
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
---
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
Constants #0000 to #03FF (binary) or &0 to &1023
(See note.)
#0000 to #03FF
(binary) or &0 to
&1023 (See note.)
Data Registers DR0 to DR15 ---
Index Registers --- ---
Indirect addressing
using Index Regis-
ters
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047,
IR15
DR0 to DR15, IR0 to IR15
---
