Timer and Counter Instructions Section 3-6
D1: 0100CH
D2: D00100
S: D00200
S+1: D00201
S+2: D00202
S+3: D00203
S+4: D00204
S+5: D00205
S+6: D00206
S+7: D00207
Reset bit
Completion Flags
Timer PV
Timer SVs
(Incrementing)
Pause bit
Corresponding completion
flag ON when SV ≤ PV.
CIO 000000
CIO 010008
CIO 010009
SV 7
SV 1
SV 0
Timer input
Timer SVs
Reset bit
PV maintained.
Timing resumes.
Completion Flags
Pause bit
Max. PV = 9999
Timer input must remain ON
while the timer is timing.
