Comparison Instructions Section 3-7
Description CPS(114) compares the signed binary data in S
1
and S
2
and outputs the
result to Arithmetic Flags (the Greater Than, Greater Than or Equal, Equal,
Less Than or Equal, Less Than, and Not Equal Flags) in the Auxiliary Area.
Note CPS(114) treats the data in S
1
and S
2
as signed binary data which ranges
from 8000 to 7FFF (
–32,768 to 32,767 decimal).
Arithmetic Flag Status
The following table shows the status of the Arithmetic Flags after execution of
CPS(114). (A status of “---” indicates that the Flag may be ON or OFF.)
Using CPS(114) Results in the Program
When CPS(114) is executed, the result is reflected in the Arithmetic Flags.
Control the desired output or right-hand instruction with a branch from the
same input condition that controls CPS(114), as shown in the following dia-
gram. In this case, the Equals Flag and output A will be turned ON when S
1
=
S
2
.
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #0000 to #FFFF
(binary)
Data Registers DR0 to DR15
Index Registers ---
Indirect addressing using
Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area S
1
S
2
(>, >=, =, <=, <, <>)
Arithmetic Flags
Signed binary
comparison
CPS(114)
Result
Flag status
>> ==< =<< >
S
1
> S
2
ON ON OFF OFF OFF ON
S
1
= S
2
OFFONONONOFFOFF
S
1
< S
2
OFF OFF OFF ON ON ON
CPS
S1
S2
A
Correct Use of CPS(114)
Arithmetic Flag
(Example: Equal Flag)
To Next Page
