Comparison Instructions Section 3-7
Description BCMP(068) compares the source data (S) to the 16 ranges defined by pairs
of lower and upper limit values in B through B+31. The first word in each pair
(B+2n) provides the lower limit and the second word (B+2n+1) provides the
upper limit of range n (n = 0 to 15). If S is within any of these ranges (inclusive
of the upper and lower limits), the corresponding bit in R is turned ON. The
rest of the bits in R will be turned OFF.
B
≤ S ≤ B+1 Bit 00 of R
B+2
≤ S ≤ B+3 Bit 01 of R
B+4
≤ S ≤ B+5 Bit 02 of R
B+6
≤ S ≤ B+7 Bit 03 of R
B+8
≤ S ≤ B+9 Bit 04 of R
B+10
≤ S ≤ B+11 Bit 05 of R
B+12
≤ S ≤ B+13 Bit 06 of R
B+14
≤ S ≤ B+15 Bit 07 of R
B+16
≤ S ≤ B+17 Bit 08 of R
B+18
≤ S ≤ B+19 Bit 09 of R
B+20
≤ S ≤ B+21 Bit 10 of R
B+22
≤ S ≤ B+23 Bit 11 of R
B+24
≤ S ≤ B+25 Bit 12 of R
B+26
≤ S ≤ B+27 Bit 13 of R
B+28
≤ S ≤ B+29 Bit 14 of R
B+30
≤ S ≤ B+31 Bit 15 of R
For example, bit 00 of R is turned ON if S is within the first range (B
≤ S ≤
B+1), bit 01 of R is turned ON if S is within the second range (B+2 ≤ S ≤ B+3),
..., and bit 15 of R is turned ON if S is within the fifteenth range (B+30
≤ S ≤
B+31). All other bits in R are turned OFF.
EM Area with bank En_00000 to
En_32767
(n = 0 to C)
En_00000 to
En_32736
(n = 0 to C)
En_00000 to
En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #0000 to #FFFF
(binary)
---
Data Registers DR0 to DR15 --- DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area S B R
