Data Movement Instructions Section 3-8
Applicable Program Areas
Operand Specifications
Description MOVL(498) transfers S+1 and S to D+1 and D. If S+1 and S are constants,
the value can be used for a data setting.
Flags
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area S D
CIO Area CIO 0000 to CIO 6142
Work Area W000 to W510
Holding Bit Area H000 to H510
Auxiliary Bit Area A000 to A958 A448 to A958
Timer Area T0000 to T4094
Counter Area C0000 to C4094
DM Area D00000 to D32766
EM Area without bank E00000 to E32766
EM Area with bank En_00000 to En_32766
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #00000000 to #FFFFFFFF
(binary)
---
Data Registers ---
Index Registers IR0 to IR15
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –) IR0 to, 1–(– –) IR5
S DS+1 D+1
Bit status
not changed.
Name Label Operation
Error Flag ER OFF
Equals Flag = ON if the contents of D+1 and D are 0000 0000 after exe-
cution.
OFF in all other cases.
Negative Flag N ON if the leftmost bit of D+1 is 1 after execution.
OFF in all other cases.
